An OEM building the control layer of a product often reaches a point where an off-the-shelf component almost fits their needs, but not quite. Functional Devices, Inc. works with manufacturers of OEM building automation systems to design, customize, and manufacture the relays, current sensors, power supplies, and controls that go into their products. This can mean modifying an existing version of a Functional Devices product, or building an entirely new product to the OEM’s specifications.

Building Automation OEMs We Design Components For

Functional Devices builds OEM components for companies whose products switch, sense, or power loads inside a building. The fit is strongest where a relay or sensor ships inside your enclosure and carries your product's reputation in the field.

  • HVAC equipment manufacturers (air handlers, rooftop units, fan coils, chillers): factory-installed pilot and power relays, control transformers, and current sensors that confirm a fan or compressor is actually running.
  • BAS controller and I/O manufacturers: relays matched to your controller's output signal, including network relays on BACnet MS/TP or BACnet/IP that extend I/O without another controller. See how RIB® relays integrate with BACnet controllers.
  • Control panel builders: track-mount relays, transformers, and power supplies sized for dense panel layouts. These are the RIB® devices panel shops use most.
  • Lighting control and fixture manufacturers: emergency lighting relays and lighting relays built into fixtures and panels. Lighting OEMs have their own guide to OEM lighting control solutions.
  • Pump, fan, and process skid builders: current sensors for proof-of-run and status, so the controller knows the motor started and not just that it was told to.

Each of these products has the same constraint. The component has to fit a space, a signal, and a listing that were set before the relay was chosen.

What an OEM Can Customize



Most OEM projects start from a production RIB® relay, current sensor, or power supply. The modified part keeps circuitry that has already shipped in volume and passed 100% end-of-line testing, so you are qualifying a change, not an unknown.

Voltage

The coil input can be matched to the signal your controller already produces: 24 Vac/dc, 120 Vac, 208–277 Vac, or a Class 2 dry-contact input. When the relay accepts your output directly, you drop the interposing relay, its wiring, and its failure point.

Form Factor

The same switching function can ship in an enclosed NEMA 1 housing, a 2.75" or 4.00" track-mount package, or a board-level format. Housing size is usually what decides whether a part fits a crowded panel or an equipment control box.

Mounting

Devices can mount by DIN rail, snap track, conduit nipple through a ½" knockout, or directly to a circuit board. Matching the mount to your assembly step cuts install time on your line.

Labeling

Private-label housings carry your brand and part number instead of ours. Housing color can also be specified for field identification, the way red housings mark relays tied to fire and life safety circuits.

Electrical Characteristics

Contact form (SPDT through 3PDT), contact rating (10 A pilot duty to 30 A power), manual override switches, LED status indication, and timing functions can all be set to the application. A relay can also be paired with a current sensor, so one device both switches the load and proves it is running.

If your requirement goes past modification, Functional Devices can design a new device to your specification.

These cover the modifications an OEM most often needs to take a proven device and make it fit a specific product. If your needs extend beyond modification, Functional Devices can also design a new product to your specifications.

Which Listings Carry Into Your Product

The listing on a component decides how much work your own product's certification takes. Settle it in stage 1 of design-in, because changing it after qualification usually means retesting.

UL Listed vs. UL Recognized Components

A UL Listed device is evaluated as a standalone product for field installation. A UL Recognized component is evaluated for use inside a larger product, with conditions of acceptability that your end-product evaluation must satisfy.

Recognized components are common inside listed equipment. A Listed relay can make field replacement and inspection simpler, because a technician can swap it without questioning the substitution. For the full distinction, see what UL Listed means.

cULus for Equipment Sold in Canada

The cULus mark shows a device was evaluated to both US and Canadian requirements. If your equipment ships into Canada, specify cULus parts at design-in rather than relisting later.

Class 2 Power

Under NEC Article 725, Class 2 sources at 24 Vac are capped at 100 VA. Specifying Class 2 transformers and power supplies keeps your low-voltage wiring in the power-limited category, which simplifies installation requirements. Sizing guidance is in low-voltage power supplies for HVAC and BAS panels.

UL 508A Panels and SCCR

If your product is an industrial control panel, its short-circuit current rating is generally limited by the lowest-rated component in the power circuit. Check each relay's and transformer's rating against the panel SCCR you need to print on the nameplate.

Private-Label Parts and Listings

UL's Multiple Listing program lets a listed product carry another company's name and model number, but it has to be filed for. Ask about this at design-in so your private-label part ships with a listing under your name.

Lighting OEMs specifying emergency circuits should also review the difference between UL924 and UL1008.

Beyond Customization: Designing a New Device



Functional Devices has the in-house design and engineering capability to develop a new component built to an OEM’s specification, if nothing in the existing portfolio meets their requirements.

This is what separates outsourcing from partnering. A catalog supplier sells what it already makes; a manufacturing partner can develop what the OEM’s product needs. For an OEM who needs a component that is not currently on the market, this means their product can be built as designed, rather than needing to be redesigned around existing limitations.

Any new device is developed against the same manufacturing controls and testing discipline as the standard Functional Devices product line.

Why OEMs Build With Functional Devices



Beyond specific customization, several things make Functional Devices a reliable manufacturing partner an OEM can build a product line with.

Made in the USA Since 1969

Functional Devices designs and manufactures its products in the United States and has done so since 1969, which affects lead-time predictability and supply stability.

ISO Certification

Functional Devices is ISO certified.

100% Product Testing

Every product is tested before it ships, and Functional Devices reports fewer than one field failure per 16,000 products.

Repeatability at Scale

Our manufacturing process is built for consistency run after run, so a component specified into a product stays the same even as the OEM’s volume grows.

How an OEM Partnership Comes Together



A partnership starts with a conversation about your needs. At Functional Devices, our Sales, Engineering, and Product teams work together to establish the opportunity, design the device, test it, and deliver it to you.

Frequently Asked Questions About OEM Building Automation Systems



What can Functional Devices customize on an OEM component?

Voltage, form factor, mounting, labeling, and electrical characteristics can all be tailored to an OEM’s needs. Beyond modifying an existing device, Functional Devices can design an entirely new component to an OEM’s specification when nothing in the current portfolio fits.

Is there a minimum order quantity for a custom or private-label device?

Functional Devices does not publish a minimum order quantity. Whether a custom or private-label project makes sense depends on the projected volume over time, which is established in conversation rather than set as a fixed number. Contact us and we can determine what makes the most sense for you.

Can Functional Devices build a device that does not exist yet?

Yes. We have the in-house design and engineering capability to develop a new component to an OEM’s specification, built against the same manufacturing and testing discipline as our standard product line.

Where are Functional Devices products made?

Functional Devices designs and manufactures its products in the United States and has done so since 1969. We are ISO-certified.

Build Your Next Component with Functional Devices

Whether it’s a modification to an existing device or a new design built to your specification, explore Functional Devices’ OEM solutions or contact Functional Devices to start the conversation about a custom OEM component.
